Features
- 32x 40G/100G/200G/400G QSFP-DD ports
- 64x 40G/200G possible via fan-out cable on the QSFP-DD ports
- 128x 10G/25G/50G/100G possible via fan-out cable on the QSFP-DD ports
- Flexible port assignment (1:1, N:N, N:1, 1:N)
- Aggregation of 1G, 10G, 25G, 40G, 50G, 100G, 200G and 400G network ports
- Support for filter rules (MAC, VLAN, IPv4/IPv6, TCP/UDP, DSCP, TCP flags, MPLS)
- Filtering within a tunnel (GTP, L2TP, MPLS, GRE, etc.)
- Aggregation and regeneration of all network traffic
- Support for user-defined filter rules (UDF)
- Multiple management options (CLI, SSH, SNMP V2/V3, WEB UI, Net CONF and REST API)
- Line rate performance without packet loss
- Non-blocking backplane architecture with N+1 redundancy
- Support for L3GRE tunnelling protocol
- Load balancing based on 5-tuple criteria
- Port Splitting (simplex mode)
- Port Labelling
- Support for Jumbo Frames
- Digital Diagnostics Monitoring (DDM)
- Radius and TACACS+
- Modular thanks to QSFP-DD interfaces
- Logging via syslog and SNMP traps
- N+1 redundant, hot-swappable fans
- Hot-swappable, load-distributing and redundant AC/DC power supply units
- Packet Slicing
- No additional licence fees per port
- Configure all PacketLion (and PacketTiger) brokers via a centralised management interface with our PacketDirector
- inclusive 1 year Silver Support
